MK3/3 Scroll Bender with Tube Bending Components

MK3/3 Scroll Bender with Tube Bending Components
Item# 33SBWTBC
$499.00

FREE Downloadable MK3/3 scroll outline sheet. CLICK HERE for .pdf file



dCombining ease of operation with the versatility the MK3/3 Scroll Bender offers, makes this a popular scroll bender.

The versatility of the MK 3/3 Scroll Bender stems from its ability to produce a range of different scroll shapes and sizes. This is achieved by interchanging 4 hinged segments.




Pictured are some of the scrolls that can be made using the MK3/3 Scroll Bender with Tubing Components.





MK3/3 SCROLL BENDER SPECIFICATIONS:

Maximum working capacity 1" x 3/16" (flat metal strip)
3/8" (solid round rod)
3/8" (solid square bar)
Max. scroll size 8 1/4" (approximate due to the varying temper
(spring) of steel)
Dimensions 14 1/4"w x 12 1/2"d x 6 1/4"h x 18 1/8" (handle radius).
Boxed Weight:28 lbs.
Max. tube dimensions 3/4" O/D. Round Tubing
Recommended wall thickness 1/16".
Dia. of small tube bender segment (inner
diameter of formed tube) 3".
Dia. of large tube bender segment (inner
diameter of formed tube) 5 1/16".
Other features Interchangeable segments to produce a whole
range of scroll sizes and shapes. Can also work
material with fish tail ends.

(the above tubing information is for guidance only and based upon the use of ERW Mild Steel Tube to the dimensions shown).







EASY TO USE - NO PRE-HEATING OF METAL REQUIRED WHEN SCROLLING

All tools are supplied with operating instructions. Please note that the maximum working
capacity stated is for Hot Rolled Material or Annealed metal. Working beyond these limits
or with material of greater hardness may reduce the operational life of the tool.

The MK3/3 Scroll Bender with tubing components is shipped in 1 box: 34 lbs.
or 28 lbs. without the tubing components (approx. weights).

Availability: Usually ships next business day.  (click photo of tool to enlarge)


VIEW VIDEO CLIPS (Windows Media Player format)

MK 3/3 Scroll Bender (Scrolling) : 0:20

highspeed

dial up

MK 3/3 Scroll Bender (Tube Bending) : 0:17

highspeed

dial up
